Dolphin 60s Scanphone Handheld Computer

Mechanical

Dimensions 136mm x 66mm x 28.7mm (5.35” x 2.60” x 1.13”)
Weight 246.6g (8.7oz)

Environmental

Operating Temperature -10° to 50°C (14°F to 122°F)
Storage Temperature -20° to 60°C (-4°F to 140°F)
Humidity 5 to 95% relative humidity (non-condensing)
Drop Designed to withstand multiple 4’ (1.2m) drops to concrete
Tumble Designed to withstand up to 800 (0.5m) tumbles per IEC 60068-2-32 specification
ESD +/- 15KV Air and +/- 8KV Contact
Environmental Sealing Independently certified to meet IP54 standards for moisture and particle intrusion

System Architecture

Processor TI AM3715 CortexA8 800 MHz
Operating System Microsoft® Windows® Embedded Handheld 6.5
Memory 256 MB RAM x 512 MB FLASH
Display 7.1cm (2.8”) color LCD QVGA (240 x 320)
Touch Panel 4-wire resistive touch panel and support for finger touch and stylus
Keypad Standard keyboards: 46-key QWERTY or 30-key Numeric, dedicated scan key,
volume up and down keys, side scan key, hard-reset key
Audio Speaker, HAC receiver, microphone
I/O Ports I/O connection(USB2.0,RS232,DC charging), Micro USB 2.0, 3.5mm headphone/mic combo jack
Camera 5.0 mega pixel camera with autofocus and flash
Storage Expansion User accessible microSD slot (SDHC compatible). Please check with your Honeywell representative for
available qualified card options.
Battery Li-ion 3.7 V, 3340 mAh
Hours of Operation 13 hours (decoding and sending data over WLAN every 9 seconds) 7.5 hours (decoding and sending data over
WWAN every 15 seconds, GPS continuously receiving data)
Decode Capabilities Dedicated imager capable of decoding standard 1D and 2D bar code symbologies
Development Environment Honeywell SDK for Microsoft® Windows® Embedded Handheld 6.5
HSM Application Software Honeywell Powertools® and Demos, Remote MasterMind™ for Mobility remote device management
Warranty 1 year factory warranty

Wireless Connectivity

WWAN
Multi-mode UMTS/HSPA+ and GSM/GPRS/EDGE operation HSPA 3GPP (DL: 14.4Mbps, UL: 5.7Mbps) with GPS
Bands supported:
• PHS8-US:- Dual band 850/1900MHz GSM/GPRS/EDGE
– Dual band 850/1900MHz UMTS/HSPA+
• PHS8-E: – Dual band 900/1800/GSM/GPRS/EDGE
– Dual band 900/2100MHz UMTS/HSPA+
• PHS8-P: – Quad band 850/900/1800/1900/GSM/GPRS/EDGE
– 800/850/900/1900/2100MHz UMTS/HSPA+
WLAN IEEE 802.11 b/g/n; WiFiTM certified
WLAN Security • DeviceScape Supplicant
• WEP, 802.1x, LEAP, TKIP, MD5, EAP-TLS, EAP-TTLS, WPA-PSK, WPA v2.0, and PEAP
WPAN 2.4 GHz (ISM Band), Bluetooth® v2.1+EDR; 10m (33’) line of sight

Features

• Lightweight Pocket-Size Design: Provides instinctive data entry and comfortable single-handed use in a compact form factor
• Durable Construction: Minimizes device repair and replacement costs with a design tested to withstand four foot drops to concrete and hundreds of 0.5 meter tumbles
• Real-Time Wireless Communication: Incorporates integrated GSM/GPRS cellular, 802.11 b/g/n WiFi, Bluetooth and GPS technologies, allowing real-time communications, access to critical data, and use of location-based services,wherever business is conducted
• Versatile Data Collection: Features an integrated 1D and 2D scan engine, a 5MP color camera, and a 2.8 inch color display, allowing manual processes to be automated
• Optimized Voice Technology: Eliminates the need for workers to carry a separate phone and has the ability to connect to a Bluetooth headset during calls
• Remote MasterMind™ Ready: Reduces total cost of ownership by providing a turnkey remote device management solution that easily manages and tracks usage of installed devices
• Service Made Simple™ Service Plans: Offers comprehensive, hassle-free protection on the device investment for up to three years after purchase, lowering the total cost of ownership
