Deskripsi
MECHANICAL
Dimension: 153.5 mm x 78.9 mm x 18 mm
(6.04 in x 3.11 in x 0.71 in)
Weight: 270 g (9.52 oz)
Display Size: 12.7 cm (5.0 in)
Resolution: 1280 x 720 High Definition
Backlight: LED
Touchscreen: Multi-touch capacitive
Hard Keys: Volume up/down key, left/right scan,
power, reset
Soft Keys: Three touch keys (Back, Home, Menu)
ENVIRONMENTAL
Operating Temperature: -10°C to +50°C
(+14°F to +122°F)
Storage Temperature: -20°C to +60°C
(-4°F to +148°F)
Humidity: 10% to 90% (non-condensing)
Drop: Multiple 1.2 m (4 ft) drops to concrete
under room temperature
Tumble: 200 times at 0.5 m (1.64 ft)
ESD: ±8 kV Direct; ±12 kV Air
Environmental Sealing: IP54
Vibration: Vertical rms = 1.04 g, Transverse
rms = 0.2 g, Longitudinal rms = 0.74 g
SYSTEM ARCHITECTURE
Processor: Qualcomm Snapdragon 410 MSM8916
1.2 GHz quad-core
Memory: 2 GB RAM, 8 GB/16 GB Flash
Operating System: Android 7.1.1 with
Google Mobile Services
Default Language: Worldwide English
Storage Expansion: MicroSDHC (up to 32 GB)
Battery: Li-Ion, 3.8 V, 4000 mAh
Button Batteries: 22 mF super-cap
Real-Time Clock: 10 min backup via super-cap
Charging Time: 4 hours
Battery Runtime: 12 hours
Scan Notification: Red/Green light
Radio Co-Location: All radios operate
simultaneously
Scan Engine: HI2D Imager
Camera: 5.0-megapixel color camera with
autofocus and LED flash
LEDs:
Battery Condition: Red/Green/Blue
Warranty: One-year factory warranty
WIRELESS CONNECTIVITY
WLAN: EEE 802.11 a/b/g/n radio
NFC
Bluetooth® Class 4.0
ACCESSORIES
Single Charging Cradle
Hand Strap
Replacement Battery
USB Communication Cable: Micro USB 2.0
(communicates to PC, supports adaptor/
USB charging)
USB Wall Adaptor: 5V/2A
Features
- An industry-leading platform: Qualcomm® Snapdragon™ 410 processor with 1.2 GHz quad-core CPU enables fast access to businesscritical applications.
- Large, 12.7 cm (5 in) Corning Gorilla® capacitive touchscreen is readable both indoors and outdoors, and works when used with wet hands.
- Lightweight design offering the user the perfect combination of durability, comfort, convenience and portability. Small enough to fit conveniently into a pocket.
- Featuring smart battery technology, the ScanPal EDA50 device can power through a full shift and beyond.
- ScanPal EDA50 devices can be easily connected to multiple devices, enabling support for more use cases and applications.
