Deskripsi
MECHANICAL
Dimensions: 162 mm x 77 mm x 18.2 mm
(6.4 in x 3.0 in x 0.7 in)
Weight: 289 g (10.1 oz) with battery pack
Display Size: 12.7 cm (5.0 in)
Resolution: High Definition (1920 x 1080)
Backlight: LED
Touchscreen: Multi-touch capacitive,
Corning Gorilla Glass 5
Hard Keys: Volume up/down key, left/right
scan, power button, push to talk button
Soft Key: On-screen scan button,
reprogrammable into an application quick
launch key
Audio: PTT button, VoIP ready, speaker,
HAC-compliant
I/O Ports: Durable, custom IO connector
ENVIRONMENTAL
Operating Temperature: -20°C to +50°C
(-4°F to +122°F)
Storage Temperature: -30°C to +70°C
(-22°F to +158°F)
Humidity: 5% to 95% (non-condensing)
Drop: Multiple 1.2 m (4 ft) drops to
concrete at -10°C to +50°C
(+14°F to +122°F).
Multiple drops from 1.8 m (6 ft) to
concrete per MIL-STD-810G with
rubber boot
Tumble: 1,000 times at 0.5 m (1.6 ft)
ESD: ±8 kV direct; ±15 kV air
Environmental Sealing: IP67 and IP65
for moisture and particle intrusion
DATA SECURITY
– FIPS 140-2 level 1 at rest
– FIPS 140-2 level 1 in motion
SYSTEM ARCHITECTURE
Processor: 2.2 GHz Qualcomm®
Snapdragon™ 660 octa-core
Memory: 4 GB DDR4x RAM, 32 GB Flash
Operating System: Starts with Android 9.1;
Guaranteed compatibility with Android R,
Committed support for Android 12 and 13
pending feasibility
Default Language: World Wide English
Storage Expansion: User-accessible
microSD card up to 512 GB (SDXC/
SDHC/SDIO-compliant)
Battery: Li-Ion, 3.85 V, 4020 mAh; smart
battery with integrated diagnostic tools,
super capacitor
Hours of Operation: 12+ hours
(depends on use)
Scan Engine: Honeywell N6700 Slim
Imager 1D/2D barcode symbologies,
Honeywell SDKs for Android
Application Software: Honeywell
utilities and demos
Camera: 13-megapixel color
camera with autofocus, 8-megapixel
front-facing camera
Sensor: Ambient light sensor, proximity
sensor, accelerometer, gyroscope
WARRANTY
One-year factory warranty
WIRELESS CONNECTIVITY
WWAN: WWAN Radio (ATT/VZW/SPRINT/
TMO/NA/EU)
LTE Advanced Support
Up to 400 Mbps CAT13 LTE downlink
Up to 75 Mbps CAT5 LTE uplink
LTE (FDD): Bands 1, 2, 3, 4,
5, 7, 8, 12, 13,
17, 19, 20, 25, 26, 28, 29
LTE (TDD): Bands 38, 39, 40, 41
UMTS/HSPA+ (3G): Bands 1, 2, 4, 5,
6, 8, 9, 19
GSM/GPRS/EDGE Quad-Band
(850/900/1800/1900 MHz)
1xRTT/EV-DO: Bands BC0, BC1, BC10
(B26BW)
WLAN: IEEE 802.11 a/b/g/n/ac; Wi-Fi
certified, 2*2 MIMO
Additional WLAN Features: 802.11
d/e/h/i/k/r/u/w
WLAN Security: OPEN, WEP, WPA/WPA2
(Personal and Enterprise)
Supported EAP: TLS, PEAP, TTLS, PWD,
LEAP CCX Version 4 certified
Bluetooth: V5.0 Bluetooth and
second BLE supported
Bluetooth Profiles: HFP, PBAP, A2DP,
AVRCP, OPP, SPP, GATT
NFC: Integrated Near Field
Communication
VPN: IPSec V4/L2TP, PPTP
Push to Talk (PTT): Supported
GPS Supported Protocols: Simultaneous
GNSS Receiver Support for GPS,
GLONASS,
Galileo and BeiDou
