Deskripsi
Industri Aplikasi:
Ruang semprot garam terutama simulasi buatan lingkungan standar korosi, digunakan untuk menguji lingkungan korosif jangka panjang pada bahan atau ketahanan korosi lapisan permukaan.Ruang uji semprotan garam banyak digunakan dalam perangkat keras, pelapisan listrik, elektronik, bahan kimia, otomotif, penerbangan, pelapis, kawat dan kabel, papan sirkuit, komunikasi dan industri lainnya.
Fitur ruang semprot garam:
- Menyediakan Host USB untuk flash drive USB
- Antarmuka kontrol operator layar sentuh.
- Kanopi yang dioperasikan secara pneumatik ‘Easy Open’.
- Gasket segel kering mencegah membasahi pakaian operator, dll.
- Ambang pemuatan rendah untuk pemuatan dan pembongkaran.
- Kapasitas besar penampung larutan garam berdiri di lantai.
- Sertifikat kalibrasi.
- Pilihan warna kanopi.
- Set rak sampel
Volume ruang percobaan:
60L / 90L / 120L / 160L / 800L (dapat disesuaikan)
Salt spray chambers Specification:
Model | HD-E808-90 |
Internal Size (L×W×H) | 900x600x500mm |
External Size (L×W×H) | 1410x880x1280mm |
Equipment Material | Both inside & outside shell adopt P.V.C rigid plastic board |
Temperature Range | Room temperature ~ 55℃ |
Temperature Fluctuations | ≤±0.5℃ |
Temperature Uniformity | ≤±2℃ |
Temperature Precision | ±1℃ |
Spraying method | Continuous and Periodic spray type |
Test Chamber Temperature | Salt Spray Method (NSS ACSS)35±1℃ Corrosion-resistant Testing Method (CASS) 50±1℃ |
Saturated air Barrel Temperature | Salt Spray Method (NSS ACSS)47±1℃ Corrosion-resistant Testing Method (CASS) 63±1℃ |
Brine Temperature | 35℃±1℃ |
Spray Quantity | 1.0~2.0 ml / 80cm2 / hr |
PH value | Salt Spray Method (NSS ACSS6.5~7.2) Corrosion-resistant Testing Method(CASS)3.0~3.2 |
Lab Volume | 270L |
Brine Tank Capacity | 25L |
Multiple Safety Protection Devices | Current discharge protection, over pressure protection, over temperature protection, over load fuse protection |
Accessories | Testing Salt/ Measuring tank/Nozzle Equipment x 1 set |
Air source | 1HP Air pump (provided by buyer) |
